Oil Free Screw Compressors

CompAir Ultima™

100% oil and silicone-free for clean air critical applications

Ultima™ is CompAir’s groundbreaking oil-free PureAir screw compressor with a unique design. It is a brand new compressor range and it utilises a low pressure and high pressure dry screw airend. Each airend is individually driven by a variable speed, permanent magnet synchronous motor, offering exceptional levels of efficiency versus traditional oil-free technology.

CompAir is always improving the best products to be even better and more cutting edge.

Contact Us
Request a Quote
Parts & Support

Ultima™ – the real deal

Ultima compressors are 100% oil and silicone-free and meet ISO 8573-1 Class Zero (2010), making them the ideal choice for stringent oil-free applications within food and beverage, pharmaceutical, electronic and the automotive industries. What makes this compressor series unique is the lack of a gearbox. Ultima uses ultra high efficiency direct drive motors which replace the gearbox and the single motor, which optimise performance throughout the complete volume range, as the airends can be driven at different speeds dependant on the demand. With a single motor driving both airends together this is not possible. This is where Ultima is hard to beat.

The Ultima utilises an intelligent “digital gearbox” design, which continuously monitors and independently adjust the speeds of each airend, ensuring maximum efficiency and pressure ratios at all times. When any regulated speed compressor gets to the minimum speed, it goes into idle run. For any compressor, this is wasted energy. Ultima uses 45% less energy in idle run than a conventional two-stage compressor and a 160kW compressor uses only 8 kW in idle run.

It is available with iConn remote monitoring. iConn is the all new and smart, proactive real-time monitoring service that delivers in-depth and real-time knowledge on the system to our compressed air users. It enables accurate production planning and total peace-of-mind protection, generating insight and statistics that keep users informed on performance, at the same time highlighting potential issues before they become a problem.

It’s compact, low maintenance, high capacity, and exceeds industrial expectations.

  • 100% oil and silicone free – Highest levels of air quality
  • Highest efficiency levels – Low running costs
  • Low noise design – Installation at point of use
  • LP & HP airends individually driven – Energy efficient across the flow range
  • Very efficient heat recovery – Most efficient machine
  • Easy installation – No ducting required
  • On-board monitoring – Very user-friendly
  • Available with iConn remote monitoring – IoT connected

Please watch the video to learn more:

Driving the perfect compressed air solution

The Delcos XXL with its high resolution 8-inch colour touch screen display, is extremely user-friendly and self-explanatory. All functions are clearly structured in five main menus and are intuitively visual. The multilingual Delcos XXL control system ensures reliable operation and protects your investment by continuously monitoring the operational parameters, essential for reducing your running costs.

CompAir Genuine Parts ensure the safe and economical operation of your system. Compliance with the maintenance intervals is essential for energy efficiency. In the event of a pressure loss due to improper filters, the high energy requirement exceeds the cost of maintenance. Do not endanger the safety of your production. Externally identical components can differ considerably.

CompAir Service Kits include all genuine parts and wear parts for the respective maintenance and ensure optimum operation of the systems.

Ultima Technical Data



BROCHURE

The unique drive design

Traditional oil-free compressors are driven by a single motor using a gearbox which in turn, drives both the low and high pressure airends. Gearboxes require oil and create friction which equates to energy loss. Ultima uses ultra high efficiency motors which replace the gearbox and the single motor which optimise performance throughout the complete volume range, as the airends can be driven at different speeds dependant on the demand. With a single motor driving both airends together this is not possible. This is where Ultima is hard to beat.

The Ultima design utilises an intelligent "digital gearbox" design which continuously monitors and independently adjust the speeds of each airend, ensuring maximum efficiency and pressure ratios at all times.

When any regulated speed compressor gets to the minimum speed, it goes into idle run. For any compressor, this is wasted energy. Ultima uses 45% less energy in idle run than a conventional two-stage compressor and a 160kW compressor uses only 8 kW in idle run.

Please watch the video to learn more about Ultima:
